| Materials | Brass body, ball and rod |
| Seals | PTFE ball seal; NBR O-Ring |
| Control element | Painted steel lever |
| Thread | DIN 259 - ISO 228 |
| Supplier code | DN ([mm]) | Dimension | Model | PN ([bar]) |
|---|---|---|---|---|
| label VS500 1'1/2 | 37,5 | 1"1/2 | VS500 | 25 |
| label VS500 1/2 | 14 | 1/2" | VS500 | 30 |
| label VS500 1' | 23,5 | 1" | VS500 | 30 |
| label VS500 2' | 47 | 2" | VS500 | 25 |
| label VS500 1'1/4 | 30 | 1"1/4 | VS500 | 25 |
| label VS500 3/4 | 18 | 3/4" | VS500 | 30 |
