| Structure | • Flexible, adaptable sealing lip • Robust, reinforced main body • Supporting studs on the suction surface |
| Suction cup material | ED-65 = ELASTODUR wear-proof |
| Accessories | Fitted filtering mesh (250 μ filter pore size) |
| Supplier code | Breaking force ([N]) | Side force ([N]) | Suction-cup ø ([mm]) | Suction power* ([N]) | Min. radius (convex) ([mm]) | Volume ([cm³]) |
|---|---|---|---|---|---|---|
| label SPF-15 ED-65 | 11,0 | 7,9 | 15 | 9,8 | 13 | 0,6 |
| label SPF-20 ED-65 | 19,2 | 10,5 | 20 | 16,0 | 25 | 1,0 |
| label SPF-25 ED-65 | 27,1 | 17,0 | 25 | 22,7 | 40 | 1,5 |
| label SPF-30 ED-65 | 35,3 | 22,5 | 30 | 29,5 | 45 | 2,3 |
| label SPF-50 ED-65 | 87,4 | 44,0 | 50 | 74,2 | 100 | 7,9 |
| label SPF-60 ED-65 | 135,0 | 65,0 | 60 | 107,0 | 75 | 12,0 |
| label SPF-40 ED-65 | 62,5 | 25,0 | 40 | 49,5 | 75 | 5,1 |
| label SPF-10 ED-65 | 5,2 | 3,5 | 10 | 4,4 | 8 | 0,2 |
