| Construction | Sturdy Aluminium alloy construction Inert spring pack Cable guide in antifriction material |
| Cable | Stainless steel (on request Polypropylene/Dyneema cable) |
| Standard supply | • Adjustable load capacity • Auxiliary safety suspension • Adjustable stroke limiting device • Safety device against load fall due to spring breakage (>3 kg) - Except models 9311 ÷ 9313 |
| Versions on request | • With capacity up to180 kg and stroke up to 3000 mm • For pneumatics, with Polyurethane tube (0.2 ÷ 5 kg) • Certified ATEX Ex II 2GD c II T 85 °C (T6), capacity from 4 to 100 kg |
| Supplier code | Flow-rate ([kg]) | Weight ([kg]) | Stroke ([mm]) |
|---|---|---|---|
| label 9322 | 4 ÷ 6 | 1,98 | 2000 |
| label 9323 | 6 ÷ 8 | 2,28 | 2000 |
| label 9321 | 2 ÷ 4 | 1,90 | 2000 |
| label 9320 | 1 ÷ 2,5 | 1,67 | 2000 |
